Q647H-16C 氣動法蘭固定球直通流道硬密封鑄鋼（WCB）球閥

概述
固定球閥的球體，采用上、下兩根閥桿固定，工作時，流體壓力不會使球體向閥座移動，閥座不會承受過大壓力而變形。
Summary
The sphere of Q47 type standing ball valve is fixed with upper and lower valve stems. When it works, for fluid pressure is unable to make sphere move towards valve base

sales@m.5yuet.cn

在線咨詢

產品圖：

可選配件：

概述

固定球閥的球體，采用上、下兩根閥桿固定，工作時，流體壓力不會使球體向閥座移動，閥座不會承受過大壓力而變形。閥桿部份設有自潤滑軸承，減少磨擦，開關扭距小，兩閥座均采用彈簧設預緊。密封采用聚氟乙烯鑲入鋼圈內，鋼圈后部設有彈簧，保證閥座緊貼球體。當閥門中腔壓力異常升高超過彈簧頂緊力，閥座后退脫離球體，達到自動泄壓效果，壓后閥座自動復位。結構的先進性使固定球閥的密封性能穩定操作省力，使用壽命長，極適用于長輸管線和一般管線。

Summary

The sphere of Q47 type standing ball valve is fixed with upper and lower valve stems. When it works, for fluid pressure is unable to make sphere move towards valve base, the valve base won't be deformed for enduring over pressure. There is self-lubricating bearing seton the part of valve stem to reduce friction, and its switch-torque is small. Both valve bases are pertensioned by setting spring. Referring to sealing, adopt the way to inset polytetrafluoroethylene into steel-ring with a spring on its rear end, which can ensure valve base cling to sphere. When the cavity pressure in valve transnormally excesses spring tension, valve base will back off and separate from sphere to get the effect of automatic pressure release.The valve base will automatically reset after being pressed. Thanks to advanced structure, the standing ball valve has stable sealing performance, labor-saved operation and long using life. It is es-pecially applicable for long conveymg pipeline and general pipeline.

結構·功能·特點Construction．Functio．Features.

全通徑設計

按照客戶的要求可以提供全通徑

或縮徑閥門，全通徑閥門具有與管子

內徑完全一致的通道直徑，減少渦流

便于清掃管道。

Full bore design

According to the customer's

demand,the fullbore orthe redu-

ced bore can be provided. The f-

ull bore valve has the diameter of

channel completely equalto the

in ner diameter of pipe to facilitat-

e to clean the pipe.

阻塞與排泄功能

固定球閥采用彈簧預緊，閥座密

封為雙活塞．利用話塞原理密封．上

下游側的閥座使流體阻斷．閥體中腔

裝放空閥排空，閥底裝有排污閥排污，

Block & Bleed Function

Fixed ball valve adopts spri-

ng to pretighten.And seat sealis

double pistons.lt adopts piston p-

rinciple to seaI.Upstr-Eam and d-

ownstream seats make fluid stop.

And the emptying valve installed

on the middle cavity is used to e-

mpty and the blowdown valve in-

stalled at the bottom of valve to c-

lear off dirt to facili-tate to clean

the pipe.

防火結構

萬一發生火災或異常升溫使PT

FE軟化燒損時，閥座支承圈防火密封

面可以和球體接觸．起到密封作用且

符合AP1607和AP16FA

Fire-proof structure

When the fire happens orthe

temperatue unusually rises to m-

ake PTFE soften to damage.the

fireproof sealsurface of seat su-

pported circle can contact with b-

all to have seal function.This co-

nforms to therequirements of A-

Pl 607 and AP16FA.

防靜電設計

采用鉻鎳不銹鋼的彈簧和小球使

球體、閥桿和閥體之間相互導電，從

而把靜電完全釋放。

Anti-static design

Chrome and nickelstainless-

teel spring and small ball are ad-

opted to make electroconductive

among ball. Stem and body to co-

mpletely releasestatic.

設計、制造標準

1、設計、制造按GB/T12237-89

2、連接法蘭JB/T 79-94

3、閥門檢查和試驗按GB/T13927-89

Standard for design and manufacture

1、DesignManafacfure According to GB/T 12237-89

2、FlangeDimensionAccording tojBfT 79-94

3、valve Check and Test According to GB/T 13927-89

主要零件材料Mater for main parts

公稱壓力Nominal PN(MPa)pressura

產品型號Product Type

主要零件材料

Parts

Material

閥體

Body

WCB

ZG1Cr18Ni9Ti

CF8

CF3

ZG1Cr18Ni-

12Mo2Ti

CF8M

CF3M

球體、閥桿

Ball,Stem

2Cr13

1Cr18Ni9Ti

0Cr19Ni9-

（304）

00Cr19Ni11-

（304L）

1Cr18Ni12-

Mo2Ti

0Cr17Ni12-

Mo（316）

00Cr19Ni14-

Mo2（316L）

閥座

Seat

四氟乙烯、對位聚苯

適用工況

Applicable

Condrtion

適用介質

Applicable mediumt

水、蒸汽、油品等

Water，Steam，Oil

硝酸等腐蝕性介質

Netricalid Corrosive

強氧化性介質

Oxgen medium

醋酸等腐蝕性介質

Acetil acid coirosive medium

尿素等腐蝕性介質

Urea corrosive medium

工作溫度（℃）

Working

Temperatdre

-29~150(四氟乙烯) -28~300(對位聚葳)

試驗壓力

（MPa）

Test pressure

殼體

Shell

1.5培

密封（液）

Sesl（liquid）

1.1培

密封（氣）

Sesl（gas）

0.6MPa

蝸輪傳動 Turbine

在手動型號的Q后插“3”表示，示例：Q347F-16C Represeting by“3”inserted befere manual“Q”

氣動 Pheumatic

在手動型號的Q后插“6”表示，示例：Q647F-16C Represetingby“6”inserted befere manual“Q”

電動 Electric

在手動型號的Q后插“9”表示．示例：Q947F-16C Represeting by“9”inserted befere manual“Q”

附注 Remark

選用縮徑球閥，在公禰通徑數值后加S表示，示例：DN100S

Selecting reduce Bore,insert“S”affer figure of DN.

如用戶選用美標的閥門請在型號前加A．選用的壓力為150Lb、300Lb、600Lb。

主要外形及連接尺寸Q647(F、N、P)-40(4.0MPa)Mani Outline and Connecting Flangs Size

公稱通徑 DN Nominal Size	外形尺寸Outline Size			連接法蘭尺寸Connecting Flangs Size						雙作用式* 執行器型號 Actuator Model of Double-acting Type
公稱通徑 DN Nominal Size	L	L1	H	D	D1	D2	C	f	n-Φd	雙作用式* 執行器型號 Actuator Model of Double-acting Type
50	178	190	260	165	125	99	20	3	4-Φ18	GTD80
65	190	210	293	185	145	118	20	3	4-Φ18	GTD90
80	203	247	323	200	160	132	20	3	8-Φ18	GTD100
100	229	276	382	220	180	156	22	3	8-Φ18	GTD115
125	356	348	468	250	210	184	22	3	8-Φ18	GTD145
150	394	378	510	285	240	211	24	3	8-Φ22	GTD160
200	457	524	655	340	295	266	24	3	12-Φ22	GTD210
250	533	645	847	405	355	319	26	3	12-Φ22	GTD255
300	610	715	980	460	410	370	28	4	12-Φ22	GTD300
350	686	795	1085	520	470	429	30	4	12-Φ22	GTD350
400	762	1860	1215	580	525	480	32	4	12-Φ22	AW35
500	991	1860	1385	715	650	609	36	4	12-Φ22	AW40

※注：系列球閥結構長度及連接法蘭尺寸可根據JB/T79標準或用戶要求設計制造。

※注：*根據不同閥門扭矩、使用介質適配或單作式的執行器型號可能有所不同，相關尺寸隨之變化。

GT系列氣動執行器可配球閥DN15~350,AW系列氣動執行器可配球閥DN150~500。

Note:The structural length and connecting flange size of ball valve series can be designed and manufactured as per JB/T 79 standard or users' reqirements.

Note:*The relative siZes are subject to change responding to the difference in

valve torque,medium and model of single-acting actuator.Pneumatic actuator of GT series may fit ball valves of DN 15-350,and that of AW series may fit ball valves of DN 150~500,P19

主要外形及連接尺寸Q647(F、N、P)-(2.5MPa)

公稱通徑 DN Nominal Size	外形尺寸Outline Size			連接法蘭尺寸Connecting Flangs Size						雙作用式* 執行器型號 Actuator Model of Double-acting Type
公稱通徑 DN Nominal Size	L	L1	H	D	D1	D2	C	f	n-Φd	雙作用式* 執行器型號 Actuator Model of Double-acting Type
50	216	210	270	165	125	99	20	3	4-Φ18	GTD90
65	241	247	309	185	145	118	22	3	4-Φ18	GTD100
80	283	276	344	200	160	132	24	3	8-Φ18	GTD115
100	305	348	421	235	190	156	24	3	8-Φ22	GTD145
125	381	378	485	270	220	184	26	3	8-Φ26	GTD160
150	403	432	559	300	250	211	28	3	8-Φ26	GTD190
200	502	524	655	360	310	274	30	3	12-Φ26	GTD210
250	568	648	847	425	370	330	32	3	12-Φ30	GTD255
300	648	715	980	485	430	389	34	4	16-Φ30	GTD300
350	762	795	1085	555	490	448	38	4	16-Φ33	GTD350
400	838	1860	1215	620	555	503	40	4	16-Φ36	AW35
500	991	1860	1385	730	660	609	44	4	20-Φ36	AW40
